The Christie Griffyn 4K50-RGB is a technological marvel that combines superior performance with advanced laser technology. With an impressive 50,000 lumens of brightness and native 4K resolution, this 3DLP RGB pure laser projector delivers vibrant, true-to-life visuals for demanding large-venue applications. Featuring Christie® TruLife+ electronics, integrated cooling, and a sealed optical path, the Griffyn 4K50-RGB promotes steadfast illumination performance, even in challenging environments.
This compact, omnidirectional projector is the lightest and brightest in its class, operating quietly at 46 dBA at full brightness. The Griffyn also offers flexibility with its high frame rate options, achieving up to 120Hz at 4K resolution or up to 480Hz at 2K resolution. With its exceptional color gamut—covering ~98% of the Rec. 2020 color space—and advanced features like integrated Christie Twist™ warping and multi-projector blending, the Griffyn 4K50-RGB is ready to elevate your projection experience.
Key Features:
-
50,000 Lumens: Provides ultra-bright, vibrant images, even in large spaces.
-
Native 4K Resolution: Delivers high-definition clarity for superior visuals.
-
RGB Pure Laser Illumination: Achieves ~98% of Rec. 2020 color space for a rich, wide color gamut.
-
Electronic Color Convergence (ECC): Easily adjust color convergence via remote control for suitable alignment.
-
Omnidirectional Design: Operates in any orientation, offering flexible installation options.
-
High Frame Rate Options: 4K at 120Hz or up to 480Hz at 2K resolution for smooth, immersive content.
-
Integrated Warping & Blending: Built-in Christie Twist™ for seamless multi-projector setups.
-
Quiet Operation: As low as 46 dBA in quiet fan mode.
Specifications:
-
Illumination Type: RGB Pure Laser
-
Brightness: 50,000 Lumens
-
Resolution: Native 4K (4096 x 2160)
-
Contrast Ratio: 2000:1 (On/Off); 5000:1 with high contrast lens
-
Throw Ratio: Varies with lens; requires lens for specific applications
-
Cooling: Liquid, self-contained
-
Laser Class: Class 1 - Risk Group 3
-
Dimensions (LxWxH): 36.3 x 25 x 15" (922 x 635 x 380mm) without lens
-
Weight: 197 lbs (89.3 kg)
-
Power Consumption: 2800W typical (9,550 BTU/hr), 3800W max (13,000 BTU/hr)
-
Sound Level: 46 dBA (quiet fan mode) / 55 dBA (standard fan mode)
-
Operating Environment: 5-40°C (41-104°F), Relative Humidity: 10-80% non-condensing
-
Supported Frame Rates: Standard: 24-60Hz | Christie Mirage option: 4K@120Hz, 4K 3D@60Hz per eye | Christie Mirage Pro option: 2K@240-480Hz, Christie View multi-content viewer
-
Inputs: 4 x 12G-SDI, 2 x HDMI 2.0, 2 x DisplayPort 1.2, Fiber (QSFP+), HDBaseT, Audio Out
-
Input Line Voltage: 200-240 VAC, 19A, 50/60Hz, Single-phase
Notes:
- Brightness may be reduced by up to 30% with high-contrast lens.
- The projector is compatible with all Christie 4K 3DLP® ILS4 lenses.
- For high brightness lenses (4.98-7.69:1), lens hood extension required for Class 1, Risk Group 3 ISO lumens.
Note: Due to ongoing research, specifications and features are subject to change without notice.
